LED Insert
    LED Insert

LED Insert

26 €
The 4 solder pins on the rear side are connected as follow:
Quantity
In stock



Safe shopping

  Types of deliveries and payments:

[see details]

  Complaints and returns:

[see details]

available payment methods

Guarantee safe & secure checkout

Delivery time shipment

Big Dog LED Inserts

The led boards are high brightness replacements for the old Big Dog led inserts. They fit a bit better in the housings compare to the common Colorado inserts. You can choose between front led boards, rear led boards and for US and EU applications.

Br = Direction indicators, brown or violet cable

Re = Rearlight bright, red cable

Di = Rearlight dimmed.

For US applications you'll need to bridge "Br" and "Re" if you use it as rear light.

DP9849
10 Items

Data sheet

Manufacturer
27404 Rhade
Axel Joost Elektronik
Dipl.-Ing. Axel Joost
Germany
Selsinger Str. 28
Producent
27404 Rhade
Axel Joost Elektronik
Dipl.-Ing. Axel Joost
Germany
Selsinger Str. 28
Solder pins
4 (Bl/Br/Re/Di)
4 (Bl/Br/Re/Di)
Available versions
Front / Rear
US / EU
